ลำโพงฮอร์นสำเร็จ TOA รุ่น CS154it

คุณสมบัติสินค้า:

หมวดหมู่ : ลำโพง ลำโพงฮอร์น

Share

Rated Input
15 W

Rated Impedance
100 V line: 670 Ω (15 W), 1 kΩ (10 W), 2 kΩ (5 W)
70 V line: 330 Ω (15 W), 670 Ω (7.5 W), 1 kΩ (5 W), 2 kΩ (2.5 W)

Sensitivity
97 dB (1 W, 1 m)

Frequency Response
150 - 15,000 Hz

Speaker Component
12 cm cone-type

Horizontal Directivity
Constant directivity horn 90゜ (±45゜ horizontal from front axis)
93 dB or more (1 W, 1 m), 3 kHz at ±45゜

Speaker Cord
2-core cabtyre cord with diameter of 6 mm

Operating Temperature
-20℃ to +55℃

Dust/Water Protection
IP65

Finish
Horn, cover: ABS resin, off-white, paint
Bracket: Stainless steel
Net: Aluminum, gray, paint
Screw: Stainless steel

Dimensions
366 (W) × 230 (H) × 272 (D) mm

Weight
2.8 kg
